10m 3mm Wall Thickness Commercial Parking Light Poles For Street Lighting

बड़ी छवि : 10m 3mm Wall Thickness Commercial Parking Light Poles For Street Lighting

उत्पाद विवरण:

उत्पत्ति के प्लेस:	China
ब्रांड नाम:	Milky Way
प्रमाणन:	/BV/ISO
मॉडल संख्या:	Galvanized Steel Pole

भुगतान & नौवहन नियमों:

न्यूनतम आदेश मात्रा:	one 40 HQ
मूल्य:	negotiation
पैकेजिंग विवरण:	as per customer request
प्रसव के समय:	usually 2 weeks after confirming
भुगतान शर्तें:	T/T
आपूर्ति की क्षमता:	300 pieces pole per day

संपर्क करें

विस्तृत उत्पाद विवरण

Optical assembly of lighting fixture:	IP65	Surface treatment:	galvanization
Standard:	ISO9001	Welding standard:	AWS D1.1
tolerance:	+/-2%	Material:	as per customer request
हाई लाइट:	galvanised steel poles , power line pole

10m 3mm Wall Thickness Commercial Parking Light Poles For Street Lighting

Specifications

10m 3mm Wall Thickness Hot Dip Galvanized Steel Pole For Street Lighting.We are considered to be one of the most professional manufacturers and exporters of Street Lighting Poles. These poles are widely installed on streets. Our offered Street Lighting Poles are wisely manufactured at our state of the art production unit utilizing superior quality of raw materials and components. All the lighting poles are manufactured in accordance with the industrial predefined parameters and guidelines. We offer a wide range of poles in different specifications to our clients at market leading prices.

Height	From 6 m to 15 m
Suit for	Airport ,seaport,plaza,stadium ,square,highway,street way etc
Shape	Conoid ,Multi-pyramidal,Columniform,polygonal or conical
Material	Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460 , ASTM573 GR65, GR50 ,SS400, SS490, to ST52-
Lamp power	20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz
Torlance of the dimenstion	+- 2%
Optical assembly of lighting fixture	IP 65
Electroshock resistant protective grade	Grade Ⅰ
The casing anti-corrosion performance	Class Ⅱ
Working atmosphere of lighting fixture	-35 ℃~+45 ℃
Surface treatment	Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Joint of Poles	Insert mode,innerflange mode,face to face joint mode .
Design of pole	Against earthquake of 8 grade
Wind Speed	160 Km/Hour
Minimum yield strength	355 mpa
Minimum ultimate tensile strength	490 mpa
Max ultimate tensile strength	620 mpa
Standard	ISO 9001
Length of per section	Within 14m once forming without slip joint
Welding	We has past flaw testing.Internal and external double welding makes the welding beautiful in shape. Welding Standard :AWS ( American Welding Society ) D 1.1
Thickness	1 mm to 30 mm
Production Process	Rew material test → Cuttingj →Molding or bending → Welidng (longitudinal ) →Dimension verify →Flange welding→Hole drilling → Calibration → Deburr →Galvanization or powder coating ,painting →Recalibration →Thread →Packages
Packages	Our poles as normal cover by Mat or straw bale at the top and bottom ,anyway also can following by client required , each 40HC or OT can loading how many pcs will calculation base on the client actually specification and data.
Style	Size and styles are veriable as per customer request

Features of Street Lighting Poles :

Engineered to perfection employing state-of-the-art production techniques
Suitable for use in different types of street lights
Excellent durability and very high service life
Excellent resistance to temperature fluctuations
Non abrasive and anti-corrosive in nature
Innovative designs with strong visual appeal

10m 3mm Wall Thickness Commercial Parking Light Poles For Street Lighting 0

Applications Area of Street Lighting Poles

Roadside lighting
Highway lighting
Lighting for traffic control
Architectural area lighting
Use in telecommunication and cellular towers
Lighting sports complexes and stadiums

10m 3mm Wall Thickness Commercial Parking Light Poles For Street Lighting 1

The street light poles of our company are made from quality sheets through bending,forming, automatic welding, hot dip galvanization and powder coating. We owned advanced production-line, it included Flatting machine, Steel plate shearer, bending machine,Auto-closed up machine, submerged arc welding machine and powder coating line, and our workmanship and quality control was achieved high opinion from our clients.

It is made of high quality steel plate that is bent and shaped by large-scale equipment and made through processes of auto welding, hot galvanizing, and alignment.With our modern equipment, we can manufacture various steel poles.

Street light's lamp panel can be made into various shapes according to different requirements.It could be

stationary or elevated automatically, as per customers' requirements.

Company Information

Jiangsu Milky Way Steel Poles Co.,Ltd. Is established in 1991, we have specialized in steel poles for more

than 24 years old. The projects we have participate in including the 2014 Sochi Olympic Games, Burj

Dubai, Dammam Seaport etc.
