13m Galvanized Light Pole Electric Telescoping Pole Columniform

चीन 13m Galvanized Light Pole Electric Telescoping Pole Columniform आपूर्तिकर्ता
13m Galvanized Light Pole Electric Telescoping Pole Columniform आपूर्तिकर्ता 13m Galvanized Light Pole Electric Telescoping Pole Columniform आपूर्तिकर्ता 13m Galvanized Light Pole Electric Telescoping Pole Columniform आपूर्तिकर्ता 13m Galvanized Light Pole Electric Telescoping Pole Columniform आपूर्तिकर्ता

बड़ी छवि :  13m Galvanized Light Pole Electric Telescoping Pole Columniform

उत्पाद विवरण:

Place of Origin: China
ब्रांड नाम: MilkyWay
प्रमाणन: ISO9001/BV/
Model Number: Electric Power Pole

भुगतान & नौवहन नियमों:

Minimum Order Quantity: 1 Poles
मूल्य: Negotation
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: L/C, T/T
Supply Ability: 300pcs per day
विस्तृत उत्पाद विवरण
Product Name: 13m 1000Dan Hot Dip Galvanized Steel Pole Electric Power Pole Columniform Application: Power Transmission
Surface treatment: Hot dip galvanization Welding standard: AWS D 1.1
Galvanization standard: ASTM A 123 Material: Steel
Voltage: 10kv to 400kv
हाई लाइट:

electric power pole

,

steel power pole

13m Galvanized Light Pole Electric Telescoping Pole Columniform


Specifications:

Type

Straight Pole ,Tensile Pole ,Turn Pole

Suit for

Electricity distribution

Shape

Conoid ,Multi-pyramidal , Columniform,polygonal or conical


Material

Usually   Q345B/A572,minimum yield strength>=345n/mm2
               Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400,
SS490, to ST52-

Tolerance of dimension

+- 2%

Power

10  KV ~550 KV

Safety Factor

Safety factor for conducting wine : 8
Safety factor for grounding wine : 8

Design Load in Kg

300~ 1000 Kg applied to 50cm from the top pole

Marks

Nane plate through rivert or glue ,engrave ,emboss as per customer
requirement

Surface treatment

Hot dip galvanized Following ASTM A 123, color polyester power or
any other standard by client required.

Joint of Poles

Insert mode,innerflange mode,face to face joint mode .

Design of pole

Against earthquake of 8 grade

Wind Speed

160 Km/Hour .  30 m /s

Minimum yield strength

355 mpa

Minimum ultimate tensile strength

490 mpa

Max ultimate tensile strength

620 mpa

Standard

ISO 9001

Length of per section

Within 14m once forming without slip joint

Welding

We have past flaw testing. Internal and external

double welding makes
the welding beautiful inshape Welding Standard :AWS ( American
Welding Society ) D 1.1

Thickness

1 mm to 30 mm

Production Process

Raw material test → Cutting →Molding or bending →

Welding
(longitudinal )→Dimension verify →Flange welding →Hole drilling
→Calibration→ Deburr →Galvanization or powder coating ,painting
→Recalibration →Thread →Packages

Packages

Our poles as normal cover by Mat or straw bale at the top

 and bottom ,
anyway also can following by client required ,each 40HC or OT can
loading how many pcs will calculation base on the client actually
specification and data.



Description:
Standard Accessory
-Top plate
-Base plate
-Bottom strip
-Standard hole
-Climbing rung
-Anchor bolt
-Bitumen protection
-Painted marking
-Removable ladder
These are the standard accessories of the electric pole.
13m Galvanized Light Pole Electric Telescoping Pole Columniform 0

Material Test:
1. All of our material are purchased from famous mill factory to assure the quality
2. A mill certificate issued by the mill factory with stamp and signature must be provided before
unload the material in our factory; otherwise we have our reason to refuse the material.
3. Before put into production, all the material must pass the chemical and physical analysis to
make sure that they have met the requested strength and component.


Production process:
As an BV, ISO,  approved supplier in China, we have more than 20 years produce and export
steel pole ,and we can assure the pole we offered is of sound quality which made from qualified material
with our professional workers and advance equipment.



13m Galvanized Light Pole Electric Telescoping Pole Columniform 1


Company Introduction:
Jiangsu Milky Way Steel Poles Co.,Ltd (Original name:Yi xing Milky Way Steel Poles Factory) was
founded in 1991 is a cooperative shares system corp. The company covers an area of 150,000 square
meter .It is now centralizing in pole design, ,research, production ,and installation. After twenty years of
development,the company owns Hot Spray Coating Zinc Branch Factory ,Anhui Steel Branch ,Milky Way
Lighting Installation Engineering Company. The total asset of the company amount to 100 million RMB
and the annual production of transmission pole comes to 20 thousand ton per year.The annual
production of steel structure comes to 10 ton and street pole of 30 thousand sets .
13m Galvanized Light Pole Electric Telescoping Pole Columniform 2
