क्रॉस आर्म्स के साथ एचडीजी 9 एम जस्ती स्ट्रीट लाइट पोल पाउडर कोटिंग

1 pcs
MOQ
बातचीत योग्य
कीमत
क्रॉस आर्म्स के साथ एचडीजी 9 एम जस्ती स्ट्रीट लाइट पोल पाउडर कोटिंग
विशेषताएं गेलरी उत्पाद विवरण एक बोली का अनुरोध
विशेषताएं
निर्दिष्टीकरण
उत्पाद का नाम: स्ट्रीट लाइट पोल
बिजली की आपूर्ति: सौर / एसी
वेल्डिंग मानक: AWS D 1.1
सामग्री: Q345
जीवन काल: 50 साल
मंदबुद्धि धार: + - 2%
समाप्त: HDG
प्रमुखता देना:

एचडीजी गैल्वेनाइज्ड स्ट्रीट लाइट ध्रुव

,

9 एम गैल्वेनाइज्ड लाइट ध्रुव

,

9 एम गैल्वेनाइज्ड स्ट्रीट लाइट ध्रुव;

मूलभूत जानकारी
Place of Origin: China
ब्रांड नाम: MilkyWay
प्रमाणन: ISO9001/BV/
Model Number: Street Light Poles
भुगतान & नौवहन नियमों
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T, L/C at sight
Supply Ability: 300pcs per day
उत्पाद विवरण

 HDG 9m Outdoor Street Light Poles Powder Coating with Cross Arms





 Specifications:

Height

From 3 meter to 15 meter

Suit for

Airport, seaport, roadway, etc

Shape

Round conical; Octagonal tapered; Straight square; Tubular stepped;

Shafts are made of steel sheet that folded into required shape and

welded longitudinally by automaticarc welding machine

Material

 Q235B or Q345 by , same grade EN44 .SS400

Tolerance of the dimension

According to client’s requirement.

Surface treatment

Hot dip galvanized Following ASTM A 123, color polyester

powder or any other standard by client required.

Joint of Poles

Slip joint, flanged connected

Base plate mounted

Base plate is square or round in shape with slotted holes for

anchor bolt and dimension as per customers requirement.

Wind Resistance

Aganist wind pressure of 160Km/h

Certificates

ISO 9001:2008

Length of per section

Within 14 meter once forming

Welding Standard

AWS (American Welding Society ) D 1.1

Thickness

1 mm to 36mm

Production Process

Raw material test → Cutting →bending →Welding (longitudinal )

→Dimension verify →Flange welding →Hole drilling →sample assemble

→ surface clean→ Galvanization or powder coating ,painting →Recalibration

→Packages

Packages

Packing with plastic paper or according to client’s request.





 Production Process

 Raw material test → Cutting →bending →Welding (longitudinal )→Dimension verify →Flange welding  →Hole drilling →sample assemble → surface clean→ Galvanization or powder coating ,painting  →Recalibration →Packages

 क्रॉस आर्म्स के साथ एचडीजी 9 एम जस्ती स्ट्रीट लाइट पोल पाउडर कोटिंग 0







 Package:

 Our poles as normal cover by Mat or straw bale at the top and bottom ,
 anyway also can following by client required , each 40HC or OT can
 loading how many pcs will calculation base on the client actually
 specification and data.

 क्रॉस आर्म्स के साथ एचडीजी 9 एम जस्ती स्ट्रीट लाइट पोल पाउडर कोटिंग 1
