Hot dip galvanized 7m solar Street Light Poles with single arm

बड़ी छवि : Hot dip galvanized 7m solar Street Light Poles with single arm

उत्पाद विवरण:

उत्पत्ति के प्लेस:	Jiangsu, China
ब्रांड नाम:	Milky Way
प्रमाणन:	ISO, BV,
मॉडल संख्या:	Hot dip galvanized 7m solar Street Light Poles with single arm

भुगतान & नौवहन नियमों:

न्यूनतम आदेश मात्रा:	one 40 HQ
मूल्य:	negotiation
पैकेजिंग विवरण:	as per customer request
प्रसव के समय:	usually 2 weeks after confirming
भुगतान शर्तें:	T/T
आपूर्ति की क्षमता:	300 pieces pole per day

संपर्क करें

विस्तृत उत्पाद विवरण

Style:	galvanization	Surface treatment:	hot dip galvanized
Height:	from 6m to 15m	Design of pole:	against earthquake of 8 grade
Wind Speed:	160km/h	Thickness:	1mm to 30mm
हाई लाइट:	street lighting poles , street lamp pole

Specification

Height	From 6 meter to 18 meter
Suit for	Airport, seaport, roadway, etc
Shape	Polygonal, Conical or Columniform
Material	Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm² As well as Hot rolled coil from ASTM A572 GR65, GR50, SS400
Tolerance of the dimension	According to client’s requirement.
Surface treatment	Hot dip galvanized Following ASTM A 123, or any other standard by client required.
Joint of Poles	Slip joint, flanged connected
Standard	ISO 9001:2008
Length of per section	Within 14 meter once forming
Welding Standard	AWS (American Welding Society ) D 1.1
Thickness	1 mm to 36mm
Production Process	Raw material test → Cutting →bending →Welding (longitudinal )→Dimension verify →Flange welding →Hole drilling →sample assemble → surface clean→ Galvanization or powder coating ,painting →Recalibration →Packages
Packages	Packing with plastic paper or according to client’s request.

Hot dip galvanized 7m solar Street Light Poles with single arm 0

Inspection

1. Material

All the raw material must be checking and testing before going the warehousing. Before production, all the material must pass the chemical and physical analysis and test to meeting the requested strength and component.

2. Insure qualified products, we take following steps for quality management :

(1) Management team: we have the overall management, especially the technical management, quality management.

(2) ISO management: with ISO 9001:2008 certificate

3. QC Inspection: all the finish product should be inspected by our QC in every production line and shipment

Hot dip galvanized 7m solar Street Light Poles with single arm 1

Terms & Conditions

1. Price Term: EXW, FOB, CFR or CIF.

The price includes pole shaft, base plate, crossarm and anchor part.

Shipping seaport: Shanghai Seaport. For FOB, CFR or CIF price, please specify which exact model you need, and tell us your order quantity so that we can calculate the local transport charges and sea freight.

2. MOQ: 1 sets.

3. Payment: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.

4. Package: Plastic paper or according to clients requirement.

5. Delivery: for 30 sets, goods can be ready for shipment within 20 workdays after receiving deposit.

6. Parts Design Service Period: 20 years.

Hot dip galvanized 7m solar Street Light Poles with single arm 2
