4-8 meters street light pole with Customizable Length and Shape for Different Applications

एक 40 एचक्यू
MOQ
बातचीत योग्य
कीमत
4-8 meters street light pole with Customizable Length and Shape for Different Applications
विशेषताएं गेलरी उत्पाद विवरण एक बोली का अनुरोध
विशेषताएं
निर्दिष्टीकरण
आयाम की सहनशीलता: +- 2%
पवन प्रतिरोध: 3-500 किमी/घंटा
सामग्री: GR50 GR65 S500 S355
ऊंचाई: 4-8 मीटर स्ट्रीट लाइट पोल
वेल्डिंग: वेल्डिंग सीडब्ल्यूबी के अंतर्राष्ट्रीय वेल्डिंग मानक के साथ पुष्टि करता है
पाउडर कोटिंग: शुद्ध पॉलिएस्टर पाउडर पेंटिंग, रंग वैकल्पिक है
डिज़ाइन: भूकंप के 8 ग्रेड के खिलाफ
प्रोडक्ट का नाम: अलग-अलग अनुप्रयोगों के लिए अनुकूलन योग्य लंबाई और आकार के साथ 4-8 मीटर स्ट्रीट लाइट पोल
मूलभूत जानकारी
उत्पत्ति के प्लेस: चीन
ब्रांड नाम: Milky Way
प्रमाणन: ISO//BV
मॉडल संख्या: अलग-अलग अनुप्रयोगों के लिए अनुकूलन योग्य लंबाई और आकार के साथ 4-8 मीटर स्ट्रीट लाइट पोल
भुगतान & नौवहन नियमों
पैकेजिंग विवरण: ग्राहक अनुरोध के अनुसार
प्रसव के समय: आमतौर पर पुष्टि के 2 सप्ताह बाद
भुगतान शर्तें: टी/टी
आपूर्ति की क्षमता: प्रति दिन 300 टुकड़े पोल
उत्पाद विवरण





Specification:



Specification: 4-8 meters street light pole
Type street light pole
Shape conical, hexagonal and octagonal
Material Usually Q345B/A572,minimum yield strength>=345n/mm2
Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52
Torlance of dimenstion -0.02
Design Load in Kg 300~ 1000 Kg appliced to 50cm from the to pole
Surface treatment Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Standard Octagonal Conical tapered column
Certified by SIRIM QAS INTERNATIONAL.
Approved by JABATAN KERJA RAYA MALAYSIA.
Conforms to Standard:
Pole design : BS EN 40
Material : BS EN 10025 S275 / JIS G3101 SS400
Welding : BS 5135
Galvanizing : BS 729 / ISO 1461 ASTM A 123
Length of per section Within 14m once forming without slip joint.
high mast pole suit for city square,wharf,stadium
Option of high mast pole Height from 20m to 35m
Flange mounted or planted type
Production Process of high mast pole Raw material test → Cutting →Molding or bending →Welidng (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration →Deburr→Galvanization or powder coating ,painting →Recalibration→Thread →Packages



4-8 meters street light pole with Customizable Length and Shape for Different Applications 0





·Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2

(Other Material is Available on Request)

·Hot Dip Galvanized (≥86um)

·Any Color Polyester Powder Coated (≥100 um)

·Taper Conical , Octagonal, Polygon Section

·With demounted bracket design,easy loaded,install,and maintenance

·Theftproof slide lock

·Category: Street lighting pole, Garden Lighting pole Solar Street lighting pole, High Mast,highmast light poles,







4-8 meters street light pole with Customizable Length and Shape for Different Applications 1
