Item |
Specification Parameter |
|
Pixel type |
Real full color |
|
Pixel color |
RGB |
|
Module size |
320*320mm |
|
Pixel led |
DIP346 |
|
Pixels pitch |
16mm |
|
Resolution rate |
32*32 |
|
Driving way |
1/4 |
|
Driving IC |
MBI5024 |
|
Working voltage |
DC5V |
|
Power |
80W |
|
Working temperature |
-30°C - +50°C |
Introduction
1. Primary Material of spot light trivision billboard advertisement : Aluminum alloy of special quality
2. Driving of spot light trivision billboard advertisement : Double-gear stepping wheel driving system
3. Specification of external frame of spot light trivision billboard advertisement : 145mm (width) * 160mm (thickness)
4. Width of triangle prism of spot light trivision billboard advertisement : 131mm, thickness 1.8mm
5. Weight: 20-25kg/square meter
6. Image combination: Triangular prism 8m without joint and no length limit
7. Image gap: 6-8mm
8. Image flipping time: Each face 6-12 seconds (preset exworks)
9. Controlling system: France Schneider Controller
10. Image stop time: Freely set from 0-900 seconds
11. Power supply: Voltage 220V, current 0.54A, frequency 50Hz, power 90W
12. Motor: 90W original Panasonic motor
13. Wind resistance: 10 class
14. Operation service life: Qualified installation will ensure nor-mal service life up to 10 years based on 16 hours each day.
15. Flipping performance (only one type can be set ex works, based on customers' requirement)
A. Simultaneous B. Wave type C. Curtain opening type D. Curtain closing type E. Flipping step by step. F. Flipping from part to part.
16. Available: for T pattern poll, upper building ads, outside building ads, intersection, etc.
Advantage
Safety: We stricly abide by design specifications and regulations by local government,making sure the safety of outdoor billboard.
Practical: The billboard structure is designed according to the human body engineering,making the worker's operation more safe,efficient and comfortable.Service doors of the billboard are equipped with dedicated anti-theft screw by independent research and development of BBD.
Beautiful: Various speficiations and types for you to choose,we also provide sample making service.
Numerical controlled machines make production more accurate and perfect.
Affordable: Digital design and management make full use of materials,reducing the cost.Precise calculation maximize the space value.Easy installation,less labor coat.
Eco-friendly and energy saving: Our products are hot dip galvanized and can be equipped with LED solar system to save resource.Besides all products can be disassembled and reused, which will reduce resource waste.
